Isolation & flow path
Confirm the required shut-off function, flow path and seat material. Include operating torque, cycling frequency and any actuation requirements.
Loading…
Your products and information will be ready in a moment.
Your products and information will be ready in a moment.
| Available Sizes | 1/4" - 1" |
|---|---|
| Size | 1/4" · 3/8" · 1/2" · 9/16" · 3/4" · 1" |
| Pressure | Up to 20000 psig; connection dependent |
| Body Material | SS316 |
| Ball Material | SS316 |
| Seat Material | PEEK |
| Operation | ROV Bucket |
| Flow Configuration | 3-way |
| Working Temperature | -18°C to +121°C; model and pressure dependent |
| Water Depth | Up to 4200 m; selected assembly |
Catalogue options. Operating limits depend on the selected size, materials and configuration.
High-pressure subsea three-way ball valve with ROV-bucket operation for routing flow between subsea lines. Specify the required flow path, end connections, design pressure, water depth, materials and project test requirements.
Applications: Subsea
For technical documentation or assistance with your selection, contact Nordic Valves.
Ball, check and needle valves for underwater installations, with lever, rocker-bar and ROV operation options.
Explore application guidanceConfirm the required shut-off function, flow path and seat material. Include operating torque, cycling frequency and any actuation requirements.
Provide internal pressure and water depth separately. Define the operation method, interface dimensions and torque requirements alongside fluid, material and testing requirements.
Listed body options: SS316. seat or seal options: PEEK. Match the selected combination to the medium and operating temperature.
Include the operating conditions in your enquiry. Add your medium, pressure, temperature and documentation requirements alongside the selected options.
